Instrument Functions
R&S
®
NRP2
131User Manual 1173.9157.02 ─ 03
Select sensor function:
[SENSe<[1]..4>]:FUNCtion[:ON] on page 268
Define calculation of measurement result:
CALCulate<[1]..8>:FEED<[1]|2> on page 223
Read result:
FETCh? on page 209
4.5.7.1 Measurement results
The measured values for the selected time slot and trace (waveform) are indicated in the
info panel below the graph.
Average / Peak / Peak/Avg
Average power, peak power and the ratio peak power to average power.
SCPI command:
Configuring measurement:
CALCulate<[1]..8>:FEED<[1]|2> on page 223
Retrieving results:
FETCh? on page 209
4.5.7.2 Controls in T'Slot display mode
Display
Selects another view, see chapter 4.5.2, "Trace window", on page 113.
Config T'slots…
Opens the subdialog "Timeslot Config" to configure the timeslot structure, see chap-
ter 4.5.7.3, "T'Slot diagram settings", on page 132.
See also chapter 4.2.1.4, "Measuring the average power of TDMA signals", on page 69,
which describes the measurement of the average power of a TDMA signal.
Pos Scale
Defines if the cursor keys position or scale the waveform.
"Pos"
The cursor keys shift the waveform in horizontal and vertical direction
"Scale"
The cursor keys expand and compress the waveform. When the hori-
zontal scaling is modified, the points (pixels) at the left of the screen
remain unchanged. When the vertical scaling is modified, the neutral
zone depends on the unit selected: the points in the center of the screen
remain unchanged when dBm, dB and dBµV are used. The points at
the bottom of the screen remain unchanged in all other displays.
Displaying traces
