Rapid 2005 - Label Placement; Figure 1: 2005; Figure 2: 2010 and 2010 B

SECTION 1: AIR HANDLER SAFETY
3 of 147
1.5 Label Placement
FIGURE 1: 2005
FIGURE 2: 2010 and 2010B
AIR FLOW
AIR FLOW
AIR FLOW
AIR FLOW
CONTROL ENCLOSURE
CONTROL ENCLOSURE
1
7
1
7
2
2
4
2
4
3
ON SHRINK WRAP
4
5
5
6
2
4
6
8
ON SHRINK WRAP BY CONTROL ENCLOSURE
9
10
9
10
11
11
12
12
Item Part Number Description
1 91070001 Label Shock Hazard
2 91070002 Label Severe Injury Hazard
3 91070003 Label Crush Hazard
4 91070004 Label Fire Hazard
5 91070005 Label Falling Hazard
6 91070006 Label Burn Hazard
7 19205 Label 2000-Series
8 91010100 Label Manual Location
9 19030 Label Recommended Entry
10 91010427 Label Vent to Outdoors
11 91010431 Label Improper Installation
12 91070015 Label Proposition 65
