B-SERIES INSTALLATION, OPERATION AND SERVICE MANUAL
30 of 147
11.2 Filter Section Assembly (2010 and 2010B)
Description Part Number
Filter Section with
Disposable Polyester Filters
Filter Section with
Permanent Aluminum Mesh Filters
77080.301[W] 77081.301[W]
Quantity Quantity
Disposable Polyester Filters 20" x 40" x 1" 23629 4 N/A
Permanent Aluminum Mesh Filters 20" x 20" x 1" 20628 N/A 8
Insulated Access Cover 77401.002[W] 1 1
Header Panel 77402.002[W] 1 1
Right Panel 77403.001[W] 1 1
Left Panel 77403.002[W] 1 1
Channel 77404.002 3 3
Support 77405.002 2 2
End Panel 77406.002[W] 1 1
Stiffener 77407.002[W] 1 1
Screw TEK3 #12 x 3/4" Washer HD 13404 38 38
Nut ¼"-20 Speed Grip 20499 4 4
Bolt ¼"-20 x ¾" HHCS 20504 4 4
¼" Flat Washer 20503 4 4
Fastener Rivnut 3/8"-16 91120106 10 10
3/8" Flatwasher 20515 10 10
3/8"-16 x 1" Bolt Hex Grade 5 20517 10 10
