SECTION 5: SPECIFICATIONS
15 of 147
Table 8: 2000-Series Selection Guide
*Temperature rise at this CFM is less than the maximum temperature rise. Heat output is based on heater operation in 100% outside
air mode.
**dBA is measured at 10' (3 m) from unducted discharge.
***Maximum Inlet Gas Pressure:ANSI - Compliant Manifold = 14 in wc (34.9 mbar)
FM and XL Compliant Manifold = 5 psi (344.7 mbar)
Airflow
CFM (m
3
/h)
Model
Motor HP at Noted
External Static
Pressure (in wc)
dBA** at Noted
External Static
Pressure (in wc)
Heat Output @ Max.
Temperature Rise
(Btu/h) x 1000
Minimum Inlet
Gas Pressure
in wc (mbar)***
Manifold Size
in NPT (mm)
0 0.250.500.751.00 0 0.50 1.00 NG LPG
1,000 (1,700) 2005 2 2 2 2 2 62 66 70 97 76 7 (17.5) 0.75 (19)
2,000 (3,400) 2005 2 2 2 2 2 60 66 70 194 151 7 (17.5) 0.75 (19)
3,000 (5,100) 2005 3 3 3 3 3 60 65 70 292 227 7 (17.5) 0.75 (19)
4,000 (6,800) 2005 3 3 3 3 3 62 65 70 389* 302 7 (17.5) 0.75 (19)
4,000 (6,800) 2010 3 3 3 3 3 59 65 69 432 346 7 (17.5) 1.0 (25)
5,000 (8,500) 2010 3 3 3 3 3 58 63 68 540 432 7 (17.5) 1.0 (25)
6,000 (10,200) 2010 5 5 5 5 5 58 62 67 648 518 7 (17.5) 1.0 (25)
7,000 (11,400) 2010 5 5 5 5 5 59 62 66 756* 605 7 (17.5) 1.0 (25)
8,000 (13,600) 2010 5 5 5 5 5 60 63 66 800* 691 7 (17.5) 1.0 (25)
9,000 (15,300) 2010 7.5 7.5 7.5 7.5 7.5 61 64 67 800* 778 7 (17.5) 1.0 (25)
10,000 (17,000) 2010 7.5 7.5 7.5 7.5 7.5 62 65 68 800* 800 7 (17.5) 1.0 (25)
7,000 (11,900) 2010B 5 5 5 5 5 59 62 66 756 605 7 (17.5) 1.25 (32)
8,000 (13,600) 2010B 5 5 5 5 5 60 63 66 864 691 7 (17.5) 1.25 (32)
9,000 (15,300) 2010B 7.5 7.5 7.5 7.5 7.5 61 64 67 972 778 7 (17.5) 1.25 (32)
10,000 (17,000) 2010B 7.5 7.5 7.5 7.5 7.5 62 65 68 1,080 864 7 (17.5) 1.25 (32)
11,000 (18,700) 2010B 10 10 10 10 10 64 66 68 1,188 950 7 (17.5) 1.25 (32)
12,000 (20,400) 2010B 10 10 10 10 10 66 68 69 1,296 1,037 7 (17.5) 1.25 (32)
13,000 (22,100) 2010B 10 10 10 10 15 67 69 CF 1,404 1,123 7 (17.5) 1.25 (32)
14,000 (23,800) 2010B 10 10 15 15 15 69 CF CF 1,512 1,210 7 (17.5) 1.25 (32)
12,000 (20,400) 2020 7.5 7.5 7.5 7.5 7.5 66 70 73 1,296 1,037 9 (22.5) 1.5 (38)
14,000 (23,800) 2020 10 10 10 10 10 69 70 73 1,512 1,210 9 (22.5) 1.5 (38)
16,000 (27,200) 2020 10 10 10 10 10 70 72 76 1,728 1,382 9 (22.5) 1.5 (38)
18,000 (30,600) 2020 15 15 15 15 15 70 74 77 1,944 1,555 9 (22.5) 1.5 (38)
20,000 (34,000) 2020 15 15 15 15 15 70 74 77 2,160 1,728 9 (22.5) 1.5 (38)
22,000 (37,400) 2020 20 20 20 20 20 71 74 77 2,376 1,901 9 (22.5) 1.5 (38)
25,000 (42,500) 2020 20 20 20 20 20 72 75 77 2,700 2,160 9 (22.5) 1.5 (38)
25,000 (42,500) 2030 15 15 15 15 15 70 72 74 2,700 2,160 11 (27.5) 2.0 (51)
27,500 (46,700) 2030 15 15 15 15 15 71 73 75 2,970 2,376 11 (27.5) 2.0 (51)
30,000 (51,000) 2030 20 20 20 25 25 73 75 76 3,240 2,592 11 (27.5) 2.0 (51)
32,500 (55,200) 2030 20 20 20 20 25 75 76 77 3,510 2,808 11 (27.5) 2.0 (51)
35,000 (59,500) 2030 20 25 25 25 25 77 77 79 3,780 3,024 11 (27.5) 2.0 (51)
37,500 (63,700) 2030 25 25 30 30 30 78 79 79 4,050 3,240 11 (27.5) 2.0 (51)
40,000 (68,000) 2030 30 30 30 30 30 80 CF CF 4,320 3,456 11 (27.5) 2.0 (51)
