Rapid 2005 - Figure 18: Stud Positioning; Figure 19: Leg Bolt Detail

SECTION 9: LEGS
25 of 147
FIGURE 18: Stud Positioning
FIGURE 19: Leg Bolt Detail
Model Part Number A B C Weight* (lbs) Weight* (kg)
2005
(in)
(cm)
77040.301[W]
38.8
98.5
10.8
27.4
9.5
24.1
26.0 11.8
2010 and
2010B
(in)
(cm)
77040.301[W]
71.0
180.3
23.5
59.7
9.5
24.1
26.0 11.8
2020
(in)
(cm)
77040.301[W]
95.0
241.3
35.0
88.9
9.5
24.1
26.0 11.8
2030
(in)
(cm)
77040.301[W]
95.0
241.3
47.0
119. 4
9.5
24.1
26.0 11.8
B
C
C
C
A C
*NOTE: Weight
shown reflects
per each leg.
46"
(116.8cm)
14.6"
(37.1 cm)
1.0"
(2.5 cm)
10.5"
(26.7 cm)
