SECTION 15: DUCT C ONSIDERATIONS
73 of 147
Table 10: Minimum Recommended Duct Size
Table 11: Discharge Duct Size Recommendations
to Connect to Heater (for BD/RD)
NOTE: Dimension clearance to clear blower
mounting bolts.
Model Height Width
2005
(in)
(cm)
14
35.6
15.6
39.7
2010 and
2010B
(in)
(cm)
24
61.0
24
61.0
2020
(in)
(cm)
32
81.3
32
81.3
2030
(in)
(cm)
38
96.5
38
96.5
Model Height Width
2005
(in)
(cm)
14
35.6
17.5
44.5
2010 and
2010B
(in)
(cm)
25.3
63.5
25.3
63.5
2020
(in)
(cm)
40
101.6
35.3
89.5
2030
(in)
(cm)
47
119. 4
40.8
103.5
