SECTION 20: MAINTENANCE

129 of 147

FIGURE 82: 6" (15.3 cm) Straight Cast Iron

FIGURE 83: 12" (30.5 cm) Straight Cast Iron

FIGURE 84: 12" (30.5 cm) Tee Cast Iron

Table 26: Burner Selections

Model Burner Length Style Qty. Drill Size

2005 6" (15.3 cm) 6" (15.3 cm) Straight 1 47

2010 1 ft (30.5 cm) 12" (30.5 cm) Straight 1 47

2010B 2 ft (61 cm) 12" (30.5 cm) Straight 2 47

2020 3.5 ft (167.6 cm)

12" (30.5 cm) Straight 1 47

6" (15.3 cm) Straight 3 47

2030 5.5 ft (167.6 cm)

12" (30.5 cm) Straight 1 47

12" (30.5 cm) Tee 3 43, 47

*Btu/hr/ft 800,000
