Rapid 2005 - SECTION 12: INLET HOOD; 12.2 Inlet Hood Assembly (2010 and 2010 B)

SECTION 12: INLET HOOD
45 of 147
12.2 Inlet Hood Assembly (2010 and 2010B)
Description
Part
Number
Inlet Hood with Permanent
Aluminum Mesh Filters
Inlet Hood Without Filters,
With Birdscreen
Inlet Hood with
Moisture Limiter
13505060 (Galvanized)
13505061 (Painted)
13505058 (Galvanized)
13505059 (Painted)
13505062 (Galvanized)
13505063 (Painted)
Quantity Quantity Quantity
Filter Rail Assembly 13505066 2 2 N/A
Top Inner Rail 13505068 1 1 1
Bottom Rail Assembly 13505072 1 1 N/A
Top Back Panel 13505075 1 1 1
Top Front Panel 13505076 1 1 N/A
Left Panel 13505080 1 1 1
Right Panel 13505081 1 1 1
Upright Mount 13505090 2 2 2
Horizontal Mount 13505091 2 2 2
Drip Rail 13505092 2 2 2
TEK Screw 13404 82 105 92
5/16-18 x 1 Bolt HHCS Grade 5 20507 5 5 5
5/16 Flat Washer 95211600 5 5 5
5/16 Nut Flange 20509 5 5 5
Permanent Filter 20" x 20" x 1" 20628 6 N/A N/A
10-24 KEPS Nut 20698 8 8 N/A
A1 Snap Fastener 20900 6 N/A N/A
10-24 x 1/2 HMS Bolt 27000 8 8 N/A
Fastener Rivnut 3/8-16 91120106 10 10 10
3/8 Flatwasher 20515 10 10 10
3/8-16 x 1 Bolt Hex Grade 5 20517 10 10 10
Foam Tape 92700017 14ft 14ft 14ft
Horizontal Mount for Birdscreen 13505087 N/A 2 N/A
Screen 38.75" x 59" 90740051 N/A 1 N/A
Fender Washer 1/4 x 1 95211550 N/A 12 N/A
Bottom Rail Assembly - ML 13505095 N/A N/A 1
Top Front Panel - ML 13505096 N/A N/A 1
Inner Support Rail - ML 13505097 N/A N/A 1
Outer Support Rail - ML 13505098 N/A N/A 1
Side Cover - ML 13505099 N/A N/A 2
Moisture Limiter Media 12" x 60" x 5.5" 90740001 N/A N/A 3
