Rapid 2005 - Table 28: Power Panel

SECTION 21: REPLACEMENT PARTS
133 of 147
Table 28: Power Panel
Voltage Description
2005 - 2030
2HP 3HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP
208/3/60
Disconnect 08036 08040 08038 08041
Contactor 90600200 90600205 90600210 90600215 90600220
Aux Contact N/A 90447000
Overload 90446010 90446025 90446035 90446040 90446045 90446050 90446055
Branch Circuit Breaker 91300500
Control Circuit Breaker 90300490
250 VA Ctrl Transformer 90407200
350VA Ctrl Transformer 90407205
Timer 90445000
Voltage Description
2005 - 2030
2HP 3HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP
230/3/60
Disconnect 08036 08040 08038 08041
Contactor 90600200 90600205 90600210 90600215 90600220
Aux Contact N/A 90447000
Overload 90446005 90446015 90446020 90446025 90446030 90446035 90446045 90446050
Branch Circuit Breaker 91300510
Control Circuit Breaker 90300490
250 VA Ctrl Transformer 90407200
350VA Ctrl Transformer 90407205
Timer 90445000
Voltage Description
2005 - 2030
2HP 3HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP
460/3/60
Disconnect 08039 08037
Contactor 90600200 90600205 90600210
Aux Contact N/A 90447000
Overload 90446005 90446005 90446015 90446020 90446025 90446030 90446035
Branch Circuit Breaker 91300520
Control Circuit Breaker 91300490
250 VA Ctrl Transformer 90407200
350VA Ctrl Transformer 90472050
Timer 90445000
Voltage Description
2005 - 2030
2HP 3HP 5HP 7.5HP 10HP 15HP 20HP 25HP 30HP
575/3/60
Disconnect 08039 08037
Contactor 90600200 90600205 90600210
Aux Contact N/A 90447000
Overload 90446000 90446005 90446015 90446020 90446025 90446030 90446035
Branch Circuit Breaker 91300530
Control Circuit Breaker 91300490
250 VA Ctrl Transformer 9047210
350VA Ctrl Transformer 90407215
Timer 90445000
Voltage Description
2005 - 2030
2HP 3HP 5HP 7.5HP 10HP
230/1/60
Disconnect 08036 08040 08038
Contactor 90600200 90600205 90600210
A
ux Contact N/A 90447000
Overload 90446015 90446020 90446030 90449035 90446040
Branch Circuit Breaker 91300510
Control Circuit Breaker 91300490
250 VA Ctrl Transformer 90407200
350VA Ctrl Transformer 90407205
Timer 90445000
