SECTION 21: REPLACEMENT PARTS
131 of 147
SECTION 21: REPLACEMENT PARTS
Replacement parts list is for general direct fired applications and MAY NOT BE APPLICABLE for your
specific unit configuration. Before ordering replacement parts, please contact factory to make sure that the
replacement parts are the direct replacement for your specific unit.
FIGURE 85: Control Panel Layouts
Carbon Monoxide Hazard
WARNING
Use only genuine RAPID
®
replacement parts per this installation, operation and service manual.
Failure to follow these instructions can result in death, electric shock, injury or property damage.
Explosion Hazard
DANGER
Electrical Shock Hazard
Fire Hazard
WARNING
Severe Injury Hazard
Use proper lifting practices and equipment.
Equipment and accessories are heavy.
Failure to follow these instructions can result
in death, injury or property damage.
WARNING
Cut/Pinch Hazard
Wear protective gear during installation,
operation and service.
Edges are sharp.
Failure to follow these instructions can result
in injury.
ELECTRICAL
TERMINALS
OPTIONAL
EQUIPMENT
AND
TERMINALS
BURNER
CONTROL
IGNITION
CONTROL
MODULE
FLAME
AMPLIFIER
OPTIONAL
RELAY
FLAME AMPLIFIER
IGNITION
TRANSFORMER
HIGH AIRFLOW
PRESSURE
SWTICH
LOW AIRFLOW
PRESSURE
SWTICH
24V
TRANSFORMER
