SECTION 21: REPLACEMENT PARTS

135 of 147

Table 31: Remote Panel Table 32: V-Belt

Description Remote Panel Part Number

Rocker Switch Center Off

DPDT

SDC & DTC 22038

Rocker Switch DPST All 22039

Remote Temperature Selector DTC 22664

Thermostat with Timer DTC 90425111

Amber Status Light All 18663

Temperature Selector Basic Remote & SDC 07345

Thermostat SDC 83200052

20VA Transformer DTC 90436900

Terminal Block All 91300121

Description Part Number

B78 Belt 04312

B81 Belt 04315

B101 Belt 04318

B105 Belt 04320

B110 Belt 04323

B130 Belt 04328

B118 Belt 04349

BX128 Belt 04352

B130 Belt 04353

BX140 Belt 04355

BX74 Belt 04362

BX78 Belt 04363

BX76 Belt 04364

B74 Belt 04365

BX123 Belt 04510
