Rapid 2005 - SECTION 5: SPECIFICATIONS; Table 9: Estimated Pressure Drop of Accessory Components

B-SERIES INSTALLATION, OPERATION AND SERVICE MANUAL
16 of 147
Table 9: Estimated Pressure Drop of Accessory Components
Model
Airflow Range
CFM (m
3
/h)
Inlet Hood with Filters Filter Section
Inlet Hood with
Moisture Limiters
Inlet Hood with
Bird Screen
in wc mbar in wc mbar in wc mbar in wc mbar
2005
1,000-2,000 (1,700-3,400) 0.25 0.62 0.25 0.62 - - 0.05 0.12
3,000-4,000 (5,100-6,800) 0.40 1.0 0.50 1.25 - - 0.05 0.12
2010
4,000-6,000 (6,800-10,200) 0.25 0.62 0.25 0.62 0.10 0.25 0.05 0.12
7,000-10,000 (11,400-17,000) 0.40 1.0 0.50 1.25 0.10 0.25 0.05 0.12
2010B
7,000-10,000 (11,400-17,000) 0.25 0.62 0.25 0.62 0.10 0.25 0.05 0.12
11,000-14,000 (18,700-23,800) 0.40 1.0 0.50 1.25 0.10 0.25 0.05 0.12
2020
12,000-16,000 (20,400-27,200) 0.25 0.62 0.25 0.62 0.10 0.25 0.05 0.12
18,000-25,000 (30,600-42,500) 0.40 1.0 0.50 1.25 0.10 0.25 0.05 0.12
2030
25,000-30,000 (42,500-51,000) 0.35 0.87 0.75 1.87 0.10 0.25 0.05 0.12
32,500-40,000 (55,200-68,000) 0.40 1.0 0.85 2.12 0.10 0.25 0.05 0.12
Model
Airflow Range
CFM (m
3
/h)
Discharge Heads Splash Plate
Inlet/Discharge
Damper
in wc mbar in wc mbar in wc mbar
2005
1,000-2,000 (1,700-3,400) 0.10 0.25 0.05 0.12 0.10 0.25
3,000-4,000 (5,100-6,800) 0.10 0.25 0.05 0.12 0.10 0.25
2010
4,000-6,000 (6,800-10,200) 0.10 0.25 0.05 0.12 0.10 0.25
7,000-10,000 (11,400-17,000) 0.10 0.25 0.05 0.12 0.10 0.25
2010B
7,000-10,000 (11,400-17,000) 0.10 0.25 0.05 0.12 0.10 0.25
11,000-14,000 (18,700-23,800) 0.10 0.25 0.05 0.12 0.10 0.25
2020
12,000-16,000 (20,400-27,200) 0.10 0.25 0.05 0.12 0.10 0.25
18,000-25,000 (30,600-42,500) 0.10 0.25 0.05 0.12 0.10 0.25
2030
25,000-30,000 (42,500-51,000) 0.10 0.25 0.05 0.12 0.10 0.25
32,500-40,000 (55,200-68,000) 0.10 0.25 0.05 0.12 0.10 0.25
