B-SERIES INSTALLATION, OPERATION AND SERVICE MANUAL
126 of 147
Drive Belts and Sheaves Check for belt ride in the groove. In multiple groove drives, belt ride should be
uniform. Check groove wear area for wear. Side wall of groove shou ld be
straight, not dished out. Bottom of groove should show no signs of belt
contact.
Sheave alignment, set screw torque and belt tension should be checked after
8, 24, and 100 hours of initial start-up. Visually inspect belts and sheaves for
excessive wear. If belts have a slick, glazed look, the belts are slipping. Check
drive capacity and belt tension. Never replace only one belt in a used set, as
used belts will elongate. Replace the entire set if replacement is necessary.
See Page 117, Section 19.2.1 and Page 118, Section 19.2.2.
Blower Bearing
Lubrication
Blowers with spider bracket bearings are pre-lubricated and do not require
any re-lubrication during their entire service life. Blowers that
use pillow block
bearings; should be re-lubricated per the chart below. The recommended
lubricant is Shell Alvania #2 or S3 grease. To re-lubricate the blower pillow
block bearings, be sure that the grease fittings on the bearing housing (or air
handler cabinet wall in the case of extended grease lines) are clean. Apply
the recommended grease to the fitting with a low-pressure grease gun and
add slowly while the shaft is spun by hand. Do not over-grease. Over-greasing
will reduce the service life of the bearings. Consult the blower manufacturer
for grease capacity recommendations as capacities vary by model.
See Page 134, Table 30 for blower manufacturer based on blower frame.
251 to 500
RPM
501 to 750
RPM
751 to 1000
RPM
812 10 7
16754
Suggested Lubrication Period in Weeks
Hours Run
Per Day
Lubrication Schedule
Use a No.2 Lithium complex base grease or equivalent
