3.6 SYSTEM SETUPS
SYSTEM MENU
I
Press
the-1
key. Press the
softkey
to select
IsysTEM~.
The SYSTEM menu contains those setup selec-
tions that effect the overall system performance.
These setups include control of input and output
data, choosing the various units of measure, cali-
bration of sensors, and a master system reset.
3.6.1
lNPIJT/OUTPUT
+
INPUT
I
OUTPUT
+
UNITS
+
CALIBRATE
+
t#srER
RESET
PRESS MENU
To
RETURN
When
thelINPUT/OUTPUTlsoftkey
is pressed from the
SYSTEM
menu, the
INPUT/OUTPUT menu screen appears. The selection of the type of Data
Input and Output, Heading, and Speed signal source are made here.
3.6.1.1 NAVIN
To select the type
ofDataInput,
press
themjsoftkeyuntilthedesired
choice appears in the box on the display.
The choices are:
INT.GPS
= Data from
Raystar
100 GPS sensor.
SEATALK
= Data from
SEATALK
network
SEATALK
NMEA
(option PCB required).
+
NAVIN
NMEA=
NMEA
0183
data from external navaid.
llNl6psIlKlLIU
+
DATAOUT
101831
0180
3.6.12 DATA OUT
+
HEADING IN
SHPSHO
m
COG/TRUE
To select the Data Output type,
press-a
key until the desired data choice appears in the
box on the display. The choices are:
+
SPEED IN
mc
~
PRESS
MENU TO RETURN
NMEAolSO
-
for older autopilot use
NMEA
0183
-
for radars, fishfinders, plotters, autopilots, etc. The NMEA
0183
data contains the
RMc,
GLL,VTG,APA,
and
BWC
sentences in its output.
OPERATION 106
