SECTION2
INSTALLATION
2.1 GENERAL
Although your
V8010
is designed to the highest levels of quality and
performance, it can best attain those standards only when it has been
properly installed. This section provides the user with practical guidelines
to assist in the planning and installation of the echo sounder unit aboard
your vessel.
2.2 UNPACKING AND INSPECTION
Use care when unpacking the unit from it’s shipping carton to prevent
damage to the contents. It is also good practice to save the carton and the
interior packing material until the unit has been satisfactorily installed on
the vessel. The original packing material should be used in the unlikely
event that it is necessary to return the unit to the factory.
22.1 Equipment Supplied
The following items should be included in the carton with your
V8010
echo sounder unit. If an item is missing, please contact your Raytheon
dealer immediately for assistance.
Table 2.1 Equipment Supplied
ITEM#
DEXXIPTION
RAYTHKON
PA’ QTY
1
V8010
Color Echo Sounder
1
2
Transducer, Type 2528L M78858
(Lexan)
1
200/50/28Khz,
1KW
or
Transducer, Type 2528B M78859 (Bronze)
1
200/50/28Khz,
1KW
INSTALLATION 9
