If no other Route operations are planned, just press the m key to
return to the previous display mode.
IMPORTANT NOTE
ALTHOUGH THIS UNIT CAN FOLLOW AROUTE PLAN MANUALLY OR AUTO-
MATICALLY THE UNIT CANNOT MAKE JUDGE- OR DECISIONS REGARD-
ING THE SAFETYOF THE VESSEL IN EXECUTING THE PLAN. THE NAVIGATOR
MUST ALWAYS BE ALERT ‘IO, AND IS RESPONSIBLE FOR, THE SAFE NAVIGA-
TION OF HIS VESSEL.
WHEN THIS UNlT IS A’ITACBED TO AN AUTOMATIC PILOT WITH AUTOMATIC
COURSE CHANGING CAPABW ALL COURSE CHANGES SHOULD BE MADE
UNDER SUCH SUPERVISION AND CONTROL.
3AAl2 Making Route Plans
The V8010 can store up to 10 different route plans. The individual route
plans may contain any number of waypoint legs as long as the total number
of route plans and waypoint legs is not greater than 100 points. In other
words, you can have 1 route plan of 100 waypoint legs or 10 route plans using
a total of 100 legs among them.
To make a route plan, press theI- key and select 71 with
On the ROUTE MENU directory, select
To MAKE a route, two steps are required:
A. First, select an available route plan number in which to store the plan.
B. Then assign the waypoints that will make up the route plan.
OPERATION 93
