A-Scope:
30% Vertical display;
ON/OFF
with any mode
Simulator:
Built-m for
Fishtinder/Plotter
Keyboard:
Silicon rubber membrane w/tactile
and audio feedback, backlighted
Power Requirements: 10.8-41 VDC
Power Consumption:
Memory Protection:
Magnetic Variation:
Geodetic Database:
Position Correction:
Selectable Units:
Route Plan:
Data Input:
Data Output:
Less than
50
watts
Internal Memory backup
-
Lithium
battery 3 to 5 years.
Automatic
WI
year table/ Manual
Selectable from 8 datums. Datums
are as follows: WGS 84 (NAD
83),
NAD-27 (USA), EURO 50, AUST 66,’
OSGB 36,
JAPAN(BESSEL)
NAD 27
(CAN), WGS 72
By Geodetic Datum or manual
L/Lentry
NM/KTS,SMiMPH,KM/KPH
10 plans;
max
of
99 WPlh.
NMEA 0183,
Seatalk,
or
GPS
Sensor
One
port.
Select
NMEA018Oor
NMEA0183*
*NMEAOW~
includes
GLL,GGA,VTG,APB,BWC,RMC,DBT
VTB.andRMB
sentences.
Data Output Rate:
Every 2 seconds for RMC and RMB;
every 4 seconds for all other data
4.62 Fishfinder Specifications
Frequency:
200 and/or
5OKhz.
TX Power:
8000 watts p-p (1000 w rms).
Sounding Rate:
600
pulses/min
(approximately).
TX
Pulse Width:
Selected by range automatically.
‘Bansducers:
T&Frequency
25282,
Lexan
,
P/C
M78858
200/50/28Khz
or
TriFrequency
2528B Bronze TH,
P/C
M788859
200/50/28Khz
