RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1111
Dec 10, 2015
(3) Peripheral Enable Register 2 (PER2)
The PER2 register is used to enable or disable supplying the clock to the peripheral hardware. Clock supply to the hardware
that is not used is also stopped so as to decrease the power consumption and noise.
To use the peripheral functions which are controlled by this register, set (1) the bit corresponding to each function before
specifying the initial settings of the peripheral functions.
This register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation sets this register to 00H.
A
ddress: F02C1H After reset: 00H R/W
Symbol 7 6 5 4 <3> <2> 1 <0>
PER2 0 0 0 0
LIN1EN
Note 1
LIN0EN 0
CAN0EN
Note 2
LIN1EN
Note 1
Control of LIN1 input clock supply
0 Stops input clock supply.
 Disables writing to the SFR used by LIN1.
 LIN1 is in the reset state.
1 Enables input clock supply.
 Enables reading from and writing to the SFR used by LIN1.
LIN0EN Control of LIN0 input clock supply
0 Stops input clock supply.
 Disables writing to the SFR used by LIN0.
 LIN0 is in the reset state.
1 Enables input clock supply.
 Enables reading from and writing to the SFR used by LIN0.
CAN0EN
Note 2
Control of CAN input clock supply
0 Stops input clock supply.
 Disables writing to the SFR used by CAN.
 CAN is in the reset state.
1 Enables input clock supply.
 Enables reading from and writing to the SFR used by CAN.
Notes 1. Only in the RL78/F14 products with at least 128 Kbytes of code flash memory and the 100-pin
products of the RL78/F14.
2. Only in the RL78/F13 (CAN and LIN incorporated) and RL78/F14 products.
Caution Be sure to clear the following bits to 0.
Bits 0, 1, 3, 4, 5, 6, and 7 in the RL78/F13 (LIN incorporated) products
Bits 1, 3, 4, 5, 6, and 7 in the RL78/F13 (CAN and LIN incorporated) products and the
RL78/F14 products with 30, 32, 48, 64, or 80 pins and up to 96 Kbytes of code flash memory
Bits 1, 4, 5, 6, and 7 in the RL78/F14 products with at least 128 Kbytes of code flash
memory and the 100-pin products of the RL78/F14
