RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 176
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (25/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After
reset
1-bit 8-bit 16-bit
F05C8H CAN RAM test register 36
Note 1
RPGACC36L RPGACC36 R/W – √ √ 0000H
F05C9H RPGACC36H – √
F05CAH CAN RAM test register 37
Note 1
RPGACC37L RPGACC37 R/W – √ √ 0000H
F05CBH RPGACC37H – √
F05CCH CAN RAM test register 38
Note 1
RPGACC38L RPGACC38 R/W – √ √ 0000H
F05CDH RPGACC38H – √
F05CEH CAN RAM test register 39
Note 1
RPGACC39L RPGACC39 R/W – √ √ 0000H
F05CFH RPGACC39H – √
F05D0H CAN RAM test register 40
Note 1
RPGACC40L RPGACC40 R/W – √ √ 0000H
F05D1H RPGACC40H – √
F05D2H CAN RAM test register 41
Note 1
RPGACC41L RPGACC41 R/W – √ √ 0000H
F05D3H RPGACC41H – √
F05D4H CAN RAM test register 42
Note 1
RPGACC42L RPGACC42 R/W – √ √ 0000H
F05D5H RPGACC42H – √
F05D6H CAN RAM test register 43
Note 1
RPGACC43L RPGACC43 R/W – √ √ 0000H
F05D7H RPGACC43H – √
F05D8H CAN RAM test register 44
Note 1
RPGACC44L RPGACC44 R/W – √ √ 0000H
F05D9H RPGACC44H – √
F05DAH CAN RAM test register 45
Note 1
RPGACC45L RPGACC45 R/W – √ √ 0000H
F05DBH RPGACC45H – √
F05DCH CAN RAM test register 46
Note 1
RPGACC46L RPGACC46 R/W – √ √ 0000H
F05DDH RPGACC46H – √
F05DEH CAN RAM test register 47
Note 1
RPGACC47L RPGACC47 R/W – √ √ 0000H
F05DFH RPGACC47H – √
F05E0H CAN RAM test register 48
Note 1
RPGACC48L RPGACC48 R/W – √ √ 0000H
F05E1H RPGACC48H – √
F05E0H CAN0 transmit/receive FIFO access
register 0AL
Note 2
CFIDL0L CFIDL0 R/W – √ √ 0000H
F05E1H CFIDL0H – √
F05E2H CAN RAM test register 49
Note 1
RPGACC49L RPGACC49 R/W – √ √ 0000H
F05E3H RPGACC49H – √
F05E2H CAN0 transmit/receive FIFO access
register 0AH
Note 2
CFIDH0L CFIDH0 R/W – √ √ 0000H
F05E3H CFIDH0H – √
F05E4H CAN RAM test register 50
Note 1
RPGACC50L RPGACC50 R/W – √ √ 0000H
F05E5H RPGACC50H – √
F05E4H CAN0 transmit/receive FIFO access
register 0BL
Note 2
CFTS0L CFTS0 R – √ √ 0000H
F05E5H CFTS0H – √
F05E6H CAN RAM test register 51
Note 1
RPGACC51L RPGACC51 R/W – √ √ 0000H
F05E7H RPGACC51H – √
F05E6H CAN0 transmit/receive FIFO access
register 0BH
Note 2
CFPTR0L CFPTR0 R/W – √ √ 0000H
F05E7H CFPTR0H – √
F05E8H CAN RAM test register 52
Note 1
RPGACC52L RPGACC52 R/W – √ √ 0000H
F05E9H RPGACC52H – √
Notes 1. These registers are allocated to the RAM window 0 for the CAN module (receive rule and CAN RAM test register).
When setting these registers, set the RPAGE bit in the GRWCR register to 0.
2. These registers are allocated to the RAM window 1 for the CAN module (receive buffer, receive FIFO buffer,
transmit/receive FIFO buffer, transmit buffer, and transmit history data). When setting these registers, set the
RPAGE bit in the GRWCR register to 1.
