RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 180
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (29/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After
reset
1-bit 8-bit 16-bit
F0632H CAN0 transmit buffer register 3AH
Note 2
TMIDH3L TMIDH3 R/W – √ √ 0000H
F0633H TMIDH3H – √
F0634H CAN RAM test register 90
Note 1
RPGACC90L RPGACC90 R/W – √ √ 0000H
F0635H RPGACC90H – √
F0636H CAN RAM test register 91
Note 1
RPGACC91L RPGACC91 R/W – √ √ 0000H
F0637H RPGACC91H – √
F0636H CAN0 transmit buffer register 3BH
Note 2
TMPTR3L TMPTR3 R/W – √ √ 0000H
F0637H TMPTR3H – √
F0638H CAN RAM test register 92
Note 1
RPGACC92L RPGACC92 R/W – √ √ 0000H
F0639H RPGACC92H – √
F0638H CAN0 transmit buffer register 3CL
Note 2
TMDF03L TMDF03 R/W – √ √ 0000H
F0639H TMDF03H – √
F063AH CAN RAM test register 93
Note 1
RPGACC93L RPGACC93 R/W – √ √ 0000H
F063BH RPGACC93H – √
F063AH CAN0 transmit buffer register 3CH
Note 2
TMDF13L TMDF13 R/W – √ √ 0000H
F063BH TMDF13H – √
F063CH CAN RAM test register 94
Note 1
RPGACC94L RPGACC94 R/W – √ √ 0000H
F063DH RPGACC94H – √
F063CH CAN0 transmit buffer register 3DL
Note 2
TMDF23L TMDF23 R/W – √ √ 0000H
F063DH TMDF23H – √
F063EH CAN RAM test register 95
Note 1
RPGACC95L RPGACC95 R/W – √ √ 0000H
F063FH RPGACC95H – √
F063EH CAN0 transmit buffer register 3DH
Note 2
TMDF33L TMDF33 R/W – √ √ 0000H
F063FH TMDF33H – √
F0640H CAN RAM test register 96
Note 1
RPGACC96L RPGACC96 R/W – √ √ 0000H
F0641H RPGACC96H – √
F0642H CAN RAM test register 97
Note 1
RPGACC97L RPGACC97 R/W – √ √ 0000H
F0643H RPGACC97H – √
F0644H CAN RAM test register 98
Note 1
RPGACC98L RPGACC98 R/W – √ √ 0000H
F0645H RPGACC98H – √
F0646H CAN RAM test register 99
Note 1
RPGACC99L RPGACC99 R/W – √ √ 0000H
F0647H RPGACC99H – √
F0648H CAN RAM test register 100
Note 1
RPGACC100L RPGACC100 R/W – √ √ 0000H
F0649H RPGACC100H – √
F064AH CAN RAM test register 101
Note 1
RPGACC101L RPGACC101 R/W – √ √ 0000H
F064BH RPGACC101H – √
F064CH CAN RAM test register 102
Note 1
RPGACC102L RPGACC102 R/W – √ √ 0000H
F064DH RPGACC102H – √
F064EH CAN RAM test register 103
Note 1
RPGACC103L RPGACC103 R/W – √ √ 0000H
F064FH RPGACC103H – √
F0650H CAN RAM test register 104
Note 1
RPGACC104L RPGACC104 R/W – √ √ 0000H
F0651H RPGACC104H – √
Notes 1. These registers are allocated to the RAM window 0 for the CAN module (receive rule and CAN RAM test register).
When setting these registers, set the RPAGE bit in the GRWCR register to 0.
2. These registers are allocated to the RAM window 1 for the CAN module (receive buffer, receive FIFO buffer,
transmit/receive FIFO buffer, transmit buffer, and transmit history data). When setting these registers, set the
RPAGE bit in the GRWCR register to 1.
To Next Page
