RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE

R01UH0368EJ0210 Rev.2.10 181

Dec 10, 2015

Table 3-6. Extended SFR (2nd SFR) List (30/32)

Address Special Function Register (2nd SFR)

Name

Symbol R/W Manipulable Bit Range After

reset

1-bit 8-bit 16-bit

F0652H CAN RAM test register 105

Note

RPGACC105L RPGACC105 R/W – √ √ 0000H

F0653H RPGACC105H – √

F0654H CAN RAM test register 106

Note

RPGACC106L RPGACC106 R/W – √ √ 0000H

F0655H RPGACC106H – √

F0656H CAN RAM test register 107

Note

RPGACC107L RPGACC107 R/W – √ √ 0000H

F0657H RPGACC107H – √

F0658H CAN RAM test register 108

Note

RPGACC108L RPGACC108 R/W – √ √ 0000H

F0659H RPGACC108H – √

F065AH CAN RAM test register 109

Note

RPGACC109L RPGACC109 R/W – √ √ 0000H

F065BH RPGACC109H – √

F065CH CAN RAM test register 110

Note

RPGACC110L RPGACC110 R/W – √ √ 0000H

F065DH RPGACC110H – √

F065EH CAN RAM test register 111

Note

RPGACC111L RPGACC111 R/W – √ √ 0000H

F065FH RPGACC111H – √

F0660H CAN RAM test register 112

Note

RPGACC112L RPGACC112 R/W – √ √ 0000H

F0661H RPGACC112H – √

F0662H CAN RAM test register 113

Note

RPGACC113L RPGACC113 R/W – √ √ 0000H

F0663H RPGACC113H – √

F0664H CAN RAM test register 114

Note

RPGACC114L RPGACC114 R/W – √ √ 0000H

F0665H RPGACC114H – √

F0666H CAN RAM test register 115

Note

RPGACC115L RPGACC115 R/W – √ √ 0000H

F0667H RPGACC115H – √

F0668H CAN RAM test register 116

Note

RPGACC116L RPGACC116 R/W – √ √ 0000H

F0669H RPGACC116H – √

F066AH CAN RAM test register 117

Note

RPGACC117L RPGACC117 R/W – √ √ 0000H

F066BH RPGACC117H – √

F066CH CAN RAM test register 118

Note

RPGACC118L RPGACC118 R/W – √ √ 0000H

F066DH RPGACC118H – √

F066EH CAN RAM test register 119

Note

RPGACC119L RPGACC119 R/W – √ √ 0000H

F066FH RPGACC119H – √

F0670H CAN RAM test register 120

Note

RPGACC120L RPGACC120 R/W – √ √ 0000H

F0671H RPGACC120H – √

F0672H CAN RAM test register 121

Note

RPGACC121L RPGACC121 R/W – √ √ 0000H

F0673H RPGACC121H – √

F0674H CAN RAM test register 122

Note

RPGACC122L RPGACC122 R/W – √ √ 0000H

F0675H RPGACC122H – √

F0676H CAN RAM test register 123

Note

RPGACC123L RPGACC123 R/W – √ √ 0000H

F0677H RPGACC123H – √

F0678H CAN RAM test register 124

Note

RPGACC124L RPGACC124 R/W – √ √ 0000H

F0679H RPGACC124H – √

F067AH CAN RAM test register 125

Note

RPGACC125L RPGACC125 R/W – √ √ 0000H

F067BH RPGACC125H – √

F067CH CAN RAM test register 126

Note

RPGACC126L RPGACC126 R/W – √ √ 0000H

F067DH RPGACC126H – √

F067EH CAN RAM test register 127

Note

RPGACC127L RPGACC127 R/W – √ √ 0000H

F067FH RPGACC127H – √

Note These registers are allocated to the RAM window 0 for the CAN module (receive rule and CAN RAM test register).

When setting these registers, set the RPAGE bit in the GRWCR register to 0.
