RL78/F13, F14
CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10
228
Dec 10, 2015
Figures 4-17 to 4-24 show block diagr
ams of port 4 for 100-pin products.
Figure 4-17. Block Diagram of
P40
P40/TOOL0
RD
WR
PORT
WR
PM
P40
TOOL0
PM4
P4
WR
PU
EV
DD
P-ch
PU4
PM40
PU40
WR
PMS
PMS
PMS0
Alternate function
Alternate function
Internal bus
Selector
Selector
Output latch
P4:
Port register 4
PU4:
Pull-up resistor option register
4
PM4:
Port mode reg
ister 4
PMS:
Port mode select register
RD: Read
signal
WRxx: Write
signal
259
261
