RL78/F13, F14
CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10
229
Dec 10, 2015
Figure 4-18. Block Diagram of
P41
P41/TI10/TO10/
TRJIO0/VCOUT0
/
SNZOUT2
RD
WR
PORT
WR
PM
P41
TO10/VCOUT0/
SNZOUT2
PM4
P4
WR
PU
EV
DD
P-ch
PU4
PM41
PU41
WR
PMS
PMS
PMS0
Alternate function
Alternate function
Internal bus
Selector
Output latch
P4:
Port register 4
PU4:
Pull-up resistor option register
4
PM4:
Port mode reg
ister 4
PMS:
Port mode select register
RD: Read
signal
WRxx: Write
signal
260
