RL78/F13, F14 CHAPTER 16 SERIAL INTERFACE IICA

R01UH0368EJ0210 Rev.2.10 1069

Dec 10, 2015

(i) When WTIM0 = 0

1: IICS0 = 1010×110B

2: IICS0 = 1010×000B

3: IICS0 = 1010×000B (Sets the WTIM0 bit to 1)

Note

4: IICS0 = 1010××00B (Sets the SPT0 bit to 1)

5: IICS0 = 00000001B

Note To generate a stop condition, set the WTIM0 bit to 1 and change the timing for generating the INTIICA0

interrupt request signal.

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care

(ii) When WTIM0 = 1

1: IICS0 = 1010×110B

2: IICS0 = 1010×100B

3: IICS0 = 1010××00B (Sets the SPT0 bit to 1)

4: IICS0 = 00001001B

Remark : Always generated

: Generated only when SPIE0 = 1

×: Don’t care

ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP

SPT0 = 1

↓

3 4 5 2 1

ST AD6 to AD0 R/W ACK D7 to D0 D7 to D0ACK ACK SP

SPT0 = 1

↓

3 4 2
