RL78/F13, F14 CHAPTER 17 LIN/UART MODULE (RLIN3)
R01UH0368EJ0210 Rev.2.10 1115
Dec 10, 2015
(7) LIN/UART Baud Rate Prescaler 0 Register (LBRPn0)
Address: F06C2H
7 6 5 4 3 2 1 0
Value after reset:
0 0 0 0 0 0 0 0
Bit Function
Setting
Range
R/W
7 to 0 Assuming that the value set in this register is N (0 to 255), the baud rate prescaler 0 divides the
frequency of the prescaler clock by N  1.
00H to FFH R/W
Set the LBRPn0 register when the OMM0 bit in the LMSTn register is 0 (LIN reset mode).
The value set in this register is used to control the frequency of baud rate clock sources fa, fb, and fc.
Assuming that the value set in this register is N, baud rate prescaler 0 divides the frequency of the clock that is selected by
the LPRS bits by N + 1.
