RL78/F13, F14 CHAPTER 18 CAN INTERFACE (RS-CAN LITE)
R01UH0368EJ0210 Rev.2.10 1386
Dec 10, 2015
Table 18-9. Registers Initialized in Global Reset Mode or Channel Reset Mode
Register Bit / Flag
CiCTRL register CHMDC[1:0]
CiCTRH register CTMS[1:0], CTME
CiSTSL register CHLTSTS, EPSTS, BOSTS, TRMSTS, RECSTS, COMSTS
CiSTSH register REC[7:0], TEC[7:0]
CiERFLL register ADERR, B0ERR, B1ERR, CERR, AERR, FERR, SERR, ALF, BLF, OVLF, BORF, BOEF, EPF, EWF, BEF
CiERFLH register CRCREG[14:0]
CFCCLk register When transmit/receive FIFO buffer is in transmit mode: CFE
CFSTSk register When transmit/receive FIFO buffer is in transmit mode: CFMC[5:0], CFTXIF, CFRXIF, CFMLT, CFFLL,
CFEMP
TMCp register TMOM, TMTAR, TMTR
TMSTSp register TMTARM, TMTRM, TMTRF[1:0], TMTSTS
TMTRSTS register TMTRSTSp
TMTCSTS register TMTCSTSp
TMTASTS register TMTASTSp
THLCCi register THLE
THLSTSi register THLMC[3:0], THLIF, THLELT, THLFLL, THLEMP
GTINTSTS register THIFi, CFTIFi, TAIFi, TSIFi
Remark i = 0, k = 0, p = 0 to 3
Table 18-10. Registers Initialized Only in Global Reset Mode
Register Bit / Flag
GSTS register GHLTSTS
GERFLL register THLES, MES, DEF
GTSC register TS[15:0]
RMND0 register RMNSn
RFCCm register RFE
RFSTSm register RFMC[5:0], RFIF, RFMLT, RFFLL, RFEMP
CFCCLk register When transmit/receive FIFO buffer is in receive mode: CFE
CFSTSk register When transmit/receive FIFO buffer is in receive mode: CFMC[5:0], CFTXIF, CFRXIF, CFMLT, CFFLL,
CFEMP
RFMSTS register RFmMLT
CFMSTS register CFkMLT
RFISTS register RFmIF
CFISTS register CFkIF
GTSTCFG register RTMPS[2:0]
GTSTCTRL register RTME
Remark k = 0, m = 0, 1, n = 0 to 15
