RL78/F13, F14 CHAPTER 24 RESET FUNCTION

R01UH0368EJ0210 Rev.2.10 1542

Dec 10, 2015

Figure 24-1. Block Diagram of Reset Function

Caution An LVD circuit internal reset does not reset the LVD circuit.

Remarks 1. LVIM: Voltage detection register

2. LVIS: Voltage detection level register

LVIRF

Internal bus

RESET

TRAP

Reset signal by watchdog timer

Set

Clear

WDCLRF IAWRF

ClearClear Clear

Set

POCRES0CLKRF

Clear

Set

Reset control flag

Power-on reset circuit reset signal

Voltage detector reset signal

Reset signal

Reset signal to LVIM/LVIS register

Reset signal by execution of illegal instruction

RESF register read signal

Reset signal by clock monitor

Reset signal by illegal-memory access

Internal bus

POR/CLM reset confirmation register

(POCRES)
