RL78/F13, F14 CHAPTER 8 TIMER RD

R01UH0368EJ0210 Rev.2.10 652

Dec 10, 2015

Figure 8-63. Operation at Compare Match between Registers TRD0 and TRDGRA0 in Complementary PWM Mode

m + 1

Count value in

TRD0 register

Value set in TRDGRA0

IMFA bit in

TRDSR0 register

TRDGRB0 register

Transferred from buffer

No change

Time

Not transferred from buffer

When bits CMD1 and CMD0 in the

TRDFCR register are set to 11B

(transfer from the buffer register to the

general register at compare match

between registers TRD0 and TRDGRA0).

TRDGRA1 register

TRDGRB1 register

Set to 0 by a program
