RL78/F13, F14 CHAPTER 12 A/D CONVERTER
R01UH0368EJ0210 Rev.2.10 718
Dec 10, 2015
Figure 12-7. Format of A/D Converter Mode Register 2 (ADM2) (2/2)
Address: F0010H After reset: 00H R/W
Symbol 7 6 5 4 <3> <2> 1 <0>
ADM2 ADREFP1 ADREFP0 ADREFM 0 ADRCK AWC 0 ADTYP
AWC Specification of the SNOOZE mode
0 Do not use the SNOOZE mode function.
1 Use the SNOOZE mode function.
When there is a hardware trigger signal in the STOP mode, the STOP mode is exited, and A/D conversion is performed
without operating the CPU (the SNOOZE mode).
The SNOOZE mode function can only be specified when the high-speed on-chip oscillator clock is selected for the
CPU/peripheral hardware clock (f
CLK). If any other clock is selected, specifying this mode is prohibited.
Using the SNOOZE mode function in the software trigger mode or hardware trigger no-wait mode is prohibited.
Using the SNOOZE mode function in the sequential conversion mode is prohibited.
When using the SNOOZE mode function, specify a hardware trigger interval of at least “shift time to SNOOZE mode
Note
+ A/D power supply stabilization wait time + A/D conversion time + 2 fCLK clocks”.
Even when using SNOOZE mode, be sure to set the AWC bit to 0 in normal operation mode and change it to 1 just
before shifting to STOP mode.
Also, be sure to change the AWC bit to 0 after returning from STOP mode to normal operation mode.
If the AWC bit is left set to 1, A/D conversion will not start normally in spite of the subsequent SNOOZE or normal
operation mode.
ADTYP Selection of the A/D conversion resolution
0 10-bit resolution
1 8-bit resolution
Note Refer to “From STOP to SNOOZE” in 23.3.3 SNOOZE mode.
Caution Only rewrite the value of the ADM2 register while conversion operation is stopped (which is
indicated by the ADCS bit of A/D converter mode register 0 (ADM0) being 0).
To Next Page
