Electrical Components
D353 6 SM
1.4 ELECTRICAL COMPONENTS
1.4.1 MAIN BOARD
1. Rear cover ( p.1 "Rear Cover")
2. Main board ( x 2, all 's)
1.4.2 LCT SET SWITCHES
Rear
1. Rear cover ( p.1 "Rear Cover")
2. Switch bracket [A] ( x 3)
3. Rear LCT set switch [B]
Front
1. Front cover ( p.2 "Front and Top Covers")
