Ricoh D009 - Ieee 802.11 A;G, G (Wireless Lan); Ieee1284; Installation Procedure

Controller Options
D009/D011/D012/D013/D091/D092 2-82 SM
2.21.2 IEEE1284
Installation Procedure
 Unplug the main machine power cord before you do the following procedure.
You can only install one of the following network interfaces at one time: (IEEE 802.11a/g, g
(Wireless LAN), IEEE1284, Bluetooth).
1. Remove the slot cover [1] from the board slot ( x 2).
2. Install the interface board (Knob-screw x 2) into the board slot.
3. Make sure that the machine can recognize the option (see "Check All Connections" at
the end of this section).
2.21.3 IEEE 802.11A/G, G (WIRELESS LAN)
Installation Procedure
 Unplug the main machine power cord before you do the following procedure.
You can only install one of the following network interfaces at one time: (IEEE 802.11a/g, g
(Wireless LAN), IEEE1284, Bluetooth).
