Component Layout
SM 3 D389
1 Bin Tray
BN3040
D389
2. DETAILS
2.1 COMPONENT LAYOUT
2.1.1 MECHANICAL COMPONENT LAYOUT
1. Exit Roller
2. Junction Gate 2* Solenoid
3. Paper Sensor
4. Paper Tray
* Junction Gate 2 is located in the main frame.
2.1.2 ELECTRICAL COMPONENT LAYOUT
1. 1-bin Control Board
2. Junction Gate 2 Solenoid
3. Paper Sensor
