Ricoh D009 - ID Sensor

PCDU
SM 4-39 D009/D011/D012/D013/D091/D092
Replacement
&
Adjustment
4.7.6 ID SENSOR
1. Left cover ( p.4-4)
2. Paper exit cover (
p.4-7)
3. Inner tray (
p.4-8)
4. Exhaust duct (
p.4-87)
5. PCDU (
p.4-32)
6. Fusing unit (
p.4-56)
7. ID sensor bracket [A] ( x 2, x 1)
8. ID sensor [B] (
x 1)
 Do SP3-001-002 to initialize the ID sensor after replacing.
