Ricoh D009 User Manual

Output Check
SM Appendix 4-257 D009/D011/D012/D013/D091/D092
Appendix:
Service
Program
Mode Tables
6145 15
Upper Junction
Gate Solenoid
Proof Junction Gate Solenoid
6145 16
Lower Junction
Gate Solenoid
Stapling Tray Junction Gate Solenoid
6145 17 Knock Solenoid Stapling Edge Pressure Plate Solenoid
6145 18
Trailing Edge Hold
Solenoid
Positioning Roller Solenoid
6145 19
Saddle Stitch Hold
Solonoid
Booklet Pressure Roller Solenoid
6145 20
Stack Junction
Gate Open/Close
Motor
Stack Junction Gate Motor
6145 21
Trailing Edge
Fence Moving
Motor
Fold Unit Bottom Fence Lift Motor
6145 22
Saddle Stitch
Staple Motor: Front
Booklet Stapler EH185R: Front
6145 23
Saddle Stitch
Staple Motor: Rear
Booklet Stapler EH185R: Rear
6145 24 Folder Plate Motor Fold Plate Motor
6145 25 Folder Roller Motor Fold Roller Motor
6145 26
Drive Roller
Oscillating Motor
Positioning Roller Motor
