Jam Detection
SM Appendix 6-7 D023/D025
Appendix
Jam
Detection
Jam Code
SP
Display Description
LCD
Display
7504 191
Finisher Entrance:
EUP (B804/B805)
Paper does not reach the finisher
entrance sensor or stays at the finisher
entrance sensor.
R1-R4
7504 192
Finisher Proof Exit:
EUP (B804/B805)
Paper does not reach the proof tray exit
sensor or stays at the proof tray exit
sensor.
R1-R4
7504 193
Finisher Shift Tray
Exit: EUP
(B804/B805)
Paper does not reach the upper tray exit
sensor or stays at the upper tray exit
sensor.
R1-R4
7504 194
Finisher Stapler Exit:
EUP (B804/B805)
Stapling tray paper sensor does not turn
on after the finisher entrance sensor has
turned on.
Stapling tray paper sensor does not turn
off after it has turned on.
R5-R7
7504 195
Finisher Exit: EUP
(B804/B805)
Upper tray exit sensor does not turn on
while the stack feed-out belt is turned
on.
Upper tray exit sensor does not turn off
after the stack feed-out belt has
returned to its home position.
R8-R12
7504 196 - - -
7504 197 - - -
