Jam Detection
D023/D025 6-8 SM Appendix
Jam Code
SP
Display Description
LCD
Display
7504 198
Finisher Folder: EUP
(B804 only)
Fold bottom fence HP sensor does not
turn on after the fold roller motor has
stopped.
Fold unit exit sensor does not turn on
after the fold rollers have stopped.
Fold unit exit sensor does not turn off
after the fold rollers have stopped.
R8-R12
7504 199
Finisher Tray Motor:
EUP (B804/B805)
Upper tray limit sensor does not turn on
after the upper tray has lifted up.
Upper tray limit sensor does not turn off
after the upper tray has moved down.
R1-R4
7504 200
Finisher Jogger Motor:
EUP (B804/B805)
Jogger fence HP sensor does not turn
on/off after the jogger motor has turned
on.
Stack feed out belt HP sensor does not
turn on/off after the feed out belt motor
has turned on.
R8-R12
7504 201
Finisher Shift Motor:
EUP (B804/B805)
Shift roller HP sensor does not turn
on/off after the shift roller motor has
turned on.
Exit guide plate HP sensor does not turn
on/off after the exit guide plate motor
has turned on.
Stacking roller HP sensor does not turn
on/off after the stacking sponge roller
motor has turned on.
R1-R4
