Ricoh D025 - Page 631

System Service Mode
SM Appendix 8-35 D023/D025
Appendix
SP Mode
Tables
011 RH Threshold S *ENG
[0 to 50 / 5 / 1 %RH/step]
012 AH Threshold S *ENG
[0 to 20 / 1 / 0.1 g/m
3
/step]
013 Non-use Time *ENG
[0 to 1440 / 360 / 10 min/step]
2015 [Charge AC Adj: Result]
001 Bk *ENG
002 M *ENG
003 C *ENG
004 Y *ENG
[0 to 9 / 0 / 1 /step]
[Color Registration Correction] FA
2101
These values are the parameters for the automatic line position adjustment
and are adjusted at the factory. However, you must input a value for
SP2101-001 after replacing the laser optics housing unit. For details, see
"Laser Optics Housing Unit" in the "Replacement and Adjustment" section. The
value should be provided with the new laser optics housing unit.
001 Main Dot: Bk *ENG
002 Main Dot: M *ENG
003 Main Dot: C *ENG
004 Main Dot: Y *ENG
[–512 to 511 / 0 / 1 dot/step]
005 Sub Line: Bk *ENG
006 Sub Line: M *ENG
007 Sub Line: C *ENG
008 Sub Line: Y *ENG
[–16384 to 16383 / 0 / 1 line/step]
