System Service Mode
D023/D025 8-36 SM Appendix
2102 [Magnification Adjustment] DFU
001 Main Mag.: High Speed: Bk *ENG
002 Main Mag.: Medium Speed: Bk *ENG
003 Main Mag.: Low Speed: Bk *ENG
004 Main Mag.: High Speed: M *ENG
005 Main Mag.: Medium Speed: M *ENG
006 Main Mag.: Low Speed: M *ENG
007 Main Mag.: High Speed: C *ENG
008 Main Mag.: Medium Speed: C *ENG
009 Main Mag.: Low Speed: C *ENG
010 Main Mag.: High Speed: Y *ENG
011 Main Mag.: Medium Speed: Y *ENG
012 Main Mag.: Low Speed: Y *ENG
These are results of the main
scan length adjustment.
[0 to 560 / 280 / 1 /step]
013 Offset: Mag Bk1-2 *ENG
014 Offset: Mag M1-2 *ENG
015 Offset: Mag C1-2 *ENG
016 Offset: Mag Y1-2 *ENG
[-256 to 255 / 0 / 1 sub-dot/step]
