System Service Mode
SM Appendix 8-125 D023/D025
Appendix
SP Mode
Tables
[Special 2: Leading Edge Correction] Special 2 Paper: Leading Edge
Correction
2821
Adjusts the correction to the paper transfer roller current at the paper leading
edge in each mode. SP2803 and SP2807 are multiplied by these SP values.
Plain: 154 mm/sec, Fine: 77 mm/sec
 The paper leading edge area can be adjusted with SP2822.
001 Paper Transfer: Plain: 1st Side *ENG
[0 to 400 / 100 / 5%/step]
002 Paper Transfer: Plain: 2nd Side *ENG
[0 to 400 / 100 / 5%/step]
003 Paper Transfer: Plain: 1st Side *ENG
[0 to 400 / 100 / 5%/step]
2821
Adjusts the correction to the discharge plate current at the paper leading edge
in each mode. SP2801 is multiplied by these SP values.
 The paper leading edge area can be adjusted with SP2822.
005 Separation DC: Plain: 1st Side *ENG
006 Separation DC: Plain: 2nd Side *ENG
007 Separation DC: Fine: 1st Side *ENG
008 Separation DC: Fine: 2nd Side *ENG
[0 to 400 / 100 / 5%/step]
