System Service Mode
D023/D025 8-168 SM Appendix
3324 [Vsg Adjustment: Set] DFU
001 SC Detection *ENG
[0 to 1 / 1 / 1p]
003 Vofset Error Counter *ENG
[0 to 99 / 0 / 0.1 time/step]
004 Vofset Threshold *ENG
[0 to 5 / 1 / 0.01 V/step]
005 Vsg Upper Threshold *ENG
[0 to 5 / 4.5 / 0.01 V/step]
006 Vsg Lower Threshold *ENG
[0 to 5 / 3.5 / 0.01 V/step]
[Vsg Adjustment Result]
3325
Displays the result of the Vsg adjustment.
The displayed numbers mean the result of each sensor (sensor for Front,
sensor for Bk, sensor for Cyan, sensor for Center, sensor for Magenta, sensor
for Yellow and sensor for Rear).
001 Latest *ENG
002 Latest 1 *ENG
003 Latest 2 *ENG
004 Latest 3 *ENG
005 Latest 4 *ENG
006 Latest 5 *ENG
007 Latest 6 *ENG
008 Latest 7 *ENG
009 Latest 8 *ENG
010 Latest 9 *ENG
[111111 to 999999 / 999999 / 1 /step]
9: Unexpected error
3: Offset voltage error
2: Vsg adjustment value error
1: O.K
