System Service Mode
SM Appendix 8-181 D023/D025
Appendix
SP Mode
Tables
3520 [ITB Idling Number]
001 Temperature: H *ENG
002 Temperature: M *ENG
003 Temperature: L *ENG
004 Temperature: L: Power ON *ENG
[0 or 3 / 0 / 1 revolution/step]
3521 [Temperature Threshold]
001 Threshold: t2 *ENG
[20 or 30 / 25 / 1 deg/step]
002 Threshold: t1 *ENG
[0 or 15 / 15 / 1 deg/step]
[Initial Process Control Setting]
3522
Adjusts the threshold for the process control at power on.
When the current condition has changed by more than the values of these SPs
when compared with the conditions at the previous operation, the process
control at power on is executed.
002 Non-use Time Setting *ENG
[0 to 1440 / 360 / 1 minute/step]
003 Temperature Range *ENG
[0 to 99 / 10 / 1°C/step]
004 Relative Humidity Range *ENG
[0 to 99 / 50 / 1 %RH/step]
005 Absolute Humidity Range *ENG
[0 to 99 / 6 / 1 g/m
3
/step]
[Rapi_timer]
100
[Time Setting] *ENG
[0 to 255 / 30 / 1 sec/step]
