System Service Mode
D023/D025 8-272 SM Appendix
5840 [IEEE 802.11b]
Channel Max *CTL
[1 to 11 or 13 / 11 or 13 / 1 /step]
Europe/Asia: 1 to 13
NA/ Asia: 1 to 11
006
Sets the maximum number of channels available for data transmission via the
wireless LAN. The number of channels available varies according to location.
The default settings are set for the maximum end of the range for each area.
Adjust the upper 4 bits to set the maximum number of channels. DFU
Do not change the setting.
Channel Min *CTL
[1 to 11 or 13 / 1 / 1 /step]
Europe: 1 to 13
NA/ Asia: 1 to 11
007
Sets the minimum number of channels available for data transmission via the
wireless LAN. The number of channels available varies according to location.
The default settings are set for the minimum end of the range for each area.
Adjust the lower 4 bits to set the minimum number of channels. DFU
Do not change the setting.
