System Service Mode
SM Appendix 8-273 D023/D025
Appendix
SP Mode
Tables
008 Transmission Speed *CTL
[0 x 00 to 0 x FF / 0 x FF to Auto / -]
0 x FF to Auto [Default]
0 x 11 – 55M Fix
0 x 10 – 48M Fix
0 x 0F – 36M Fix
0 x 0E – 18M Fix
0 x 0D – 12M Fix
0 x 0B – 9M Fix
0 x 0A – 6M Fix
0 x 07 – 11M Fix
0 x 05 – 5.5M Fix
0 x 08 – 1M Fix
0 x 13 – 0 x FE (reserved)
0 x 12 – 72M (reserved)
0 x 09 – 22M (reserved)
011 WEP key Select *CTL
Selects the WEP key.
[00 to 11 / 00 / 1 binary]
00: Key #1
01: Key #2 (Reserved)
10: Key #3 (Reserved)
11: Key #4 (Reserved)
042 Fragment Thresh *CTL
Adjusts the fragment threshold for the
IEEE802.11 card.
[256 to 2346 / 2346 / 1]
This SP is displayed only when the
IEEE802.11 card is installed.
043 1g CTS to Self *CTL
Determines whether the CTS self function
is turned on or off.
[0 to 1 / 1 / 1] 0: Off, 1: On
This SP is displayed only when the
IEEE802.11 card is installed.
