Ricoh D025 - Page 902

System Service Mode
D023/D025 8-306 SM Appendix
6148 [Jogger Fine Adj]
*ENG Fine Adjust Output Jogger Unit Fences
001 A3T
002 B4T
003 A4T
004 A4Y
005 B5Y
006 A5Y
007 DLT-T
008 LG-T
009 LT-T
010 LT-Y
011 HLT-Y
012 Other
This SP corrects the distance between the jogger
fences and the sides of the stack when the output
jogger unit attached to the side of the machine jogs
sheets as they exit the finisher.
+ Value:
Increases distance between jogger fences and the
sides of the stack.
- Value:
Decreases the distance between the jogger fences
and the sides of the stack.
[-1.5 to 1.5 / 0 / 0.5 mm/step]
[Max. Pre-Stack Sheet]
*ENG Number of Pre-Stack Sheets
6149
This SP sets the number of sheets sent to the pre-stack tray.
Note:
You may need to adjust this setting or switch it off when feeding thick or slick
paper.
001 -
[0 to 3 / 3 / 1 sheet/step]
