Ricoh D025 - Page 903

System Service Mode
SM Appendix 8-307 D023/D025
Appendix
SP Mode
Tables
[INPUT Check]
6150
Displays the signals received from sensors and switches of the bridge unit
(D386) ( "Input Check Table" in this section).
[OUTPUT Check]
6151
Displays the signals received from sensors and switches of the brisge unit
(D386) ( "Output Check Table" in this section).
[INPUT Check]
6152
Displays the signals received from sensors and switches of the shift tray
(D388) ( "Input Check Table" in this section).
[OUTPUT Check]
6153
Displays the signals received from sensors and switches of the shift tray
(D388) ( "Output Check Table" in this section).
[INPUT Check]
6154
Displays the signals received from sensors and switches of the 1 bin tray
(D414) ( "Input Check Table" in this section).
[OUTPUT Check]
6155
Displays the signals received from sensors and switches of the 1 bin tray
(D414) ( "Output Check Table" in this section)
001 1 bin: Junction Solenoid
