COMPONENT LAYOUT AND PAP
ER PATH
SM 13
G390
G390
Duplex Unit
2.
DET
AILED SECTION DESCRIPTIONS
2.1
COMPONENT LAYOUT AND PAPER PATH
1.
Paper gate (of the printer)
2. Entrance
roller
3.
Upper transport roller
4.
Paper gate solenoid
5.
Paper sensor 1
6.
Lower transport roller
7. Inverting
roller
8.
Paper sensor 2
9. Exit
roller
G390D901.
WMF
2
1
3
4
5
6
7
8
9
270
272
