2.Mechanism
16
2. Mechanism
Overview
System Components
Hardware Specifications
Components
No. Name No. Name
1 Speaker 13 [Check Status] indicator
2 [Login/Logout] key 14 [Check Status] key
3 Main power indicator 15 Data In indicator (facsimile and printer modes)
4 [Energy Saver] key 16 Fax indicator
5 USB slot for digital cameras 17 Extended Feature key (EX3)
6 HDMI slot 18 Extended Feature key (EX2)
7 USB slot for NFC card readers 19 Extended Feature key (EX1)
8 Microphone 20 Control panel reboot key
9 [Stop] key 21 SD card slot
10 [Menu] key 22 Media access lamp
11 [Home] key 23 USB slot
12 [Back] key
Basic Specifications
Category Specification
LCD panel
• Size
