1.Replacement and Adjustment
10
3. Base bracket [A] ( ×9)
4. Wi-Fi module [A] ( ×1)
• After replacing the Wi-Fi module, perform the following checks:
• Wireless LAN Check (Wireless LAN Check)
• Bluetooth Check (Bluetooth Check)
LCD
1. Operation panel unit (Operation Panel Unit)
2. CPU board (CPU Board)
3. Micro computer board (Micro Computer Board)
