Bypass
301
4. Remove the bypass paper width sensor [A]. (Hooks × 4)
Bypass Feed Roller
Before Replacing the Bypass Feed Roller
Before replacing the bypass feed roller, reset the PM counter.
1. Turn the power ON.
2. Reset the PM counter. (Refer to Replacement Procedure of the PM/Yield Parts)
3. Turn the power OFF.
Replacing the Bypass Feed Roller
1. Remove the bypass feed unit. (Bypass Feed Unit)
To Next Page
