Ricoh MP C307

Paper Feed
293
Tray Lift Sensor
1. Remove the waste toner bottle. (Waste Toner Bottle)
2. Remove the tray lift sensor [A]. ( × 1, hook × 2)
Draw-in Unit
1. Remove the PSU fan. (PSU Fan)
2. Remove the rear cover. (Rear Cover)
3. Remove the screw. ( × 1)
4. Remove the draw-in unit [A] with bracket. ( × 2)
